Omron NX102-1120
(NX102-1120)
Sepetteki Son Fiyat
Fiyat
:
₺0,00 + KDV
KDV Dahil
:
₺0,00
Sepet Fiyatı
:
FİYAT VE TESLİM SÜRESİ İÇİN LÜTFEN İLETİŞİME GEÇİNİZ!
Sysmac NX1 Modular CPU with with Database Connectivity, 5MB program and 33.5MB data memory , built-in EtherCAT (4 servo axes, 4 PTP axes, total 64 EtherCAT nodes), 2 Ethernet ports (OPC-UA and EtherNet/IP)
FİYAT VE TESLİM SÜRESİ İÇİN LÜTFEN İLETİŞİME GEÇİNİZ!
| Controller functionality |
DB connection, Motion control, OPC-UA, Position control, Sequence control |
| Max. number of synchronous axes |
4 |
| Max. number of PTP axes |
4 |
| Max. number of axes (incl. virtual) |
15 |
| Primary task cycle time |
1 ms |
| Program memory |
5 MB |
| Variables memory |
33.5 MB |
| Communication port(s) |
EtherCAT Master, EtherNet/IP, Ethernet TCP/IP, USB |
| Communication option(s) |
Serial RS-232C, Serial RS-422, Serial RS-485 |
| Max. number of remote I/O nodes |
64 |
| I/O system |
NX I/O Bus |
| Max. number of expansion units |
32 |
| Height |
100 mm |
| Width |
66 mm |
| Depth |
100 mm |
| Weight |
470 g |
