Omron NX-AD2603
(NX-AD2603)
Sepetteki Son Fiyat
Fiyat
:
₺0,00 + KDV
KDV Dahil
:
₺0,00
Sepet Fiyatı
:
FİYAT VE TESLİM SÜRESİ İÇİN LÜTFEN İLETİŞİME GEÇİNİZ!
2 Analog Inputs, -10 to 10 V single ended, resolution 1:8000, 250 µs/ch, screwless push-in connector, 12 mm wide
FİYAT VE TESLİM SÜRESİ İÇİN LÜTFEN İLETİŞİME GEÇİNİZ!
| I/O system |
NX I/O Bus |
| Type of module |
Analog I/O |
| Number of analog inputs |
2 |
| Temperature input type |
None |
| Linear analog input type |
-10 to 10 V |
| Resolution of the analog inputs |
13 Bit |
| Input circuit type |
Single-ended |
| Number of analog outputs |
0 |
| Linear analog output type |
None |
| Conversion time |
0.5 ms/unit |
| Signal processing |
Free running |
| IO link master |
x |
| I/O connection type |
Push-in |
| Number of I/O connectors |
1 |
| Detachable I/O connector |
|
| Suitable for safety functions |
x |
| SIL according to IEC 61508 |
None |
| Degree of protection (IP) |
IP20 |
| Height |
100 mm |
| Width |
12 mm |
| Depth |
71 mm |
| Weight |
70 g |
