Omron G3PA-450B-VD-2 12-24VDC
(G3PA-450B-VD-2 12-24VDC)
Sepetteki Son Fiyat
Fiyat
:
₺0,00 + KDV
KDV Dahil
:
₺0,00
Sepet Fiyatı
:
FİYAT VE TESLİM SÜRESİ İÇİN LÜTFEN İLETİŞİME GEÇİNİZ!
FİYAT VE TESLİM SÜRESİ İÇİN LÜTFEN İLETİŞİME GEÇİNİZ!
| Application |
ON/OFF control |
| Number of phases |
1 |
| Number of poles |
1 |
| Mounting method |
DIN rail |
| Terminal |
Screw |
| With LED indicator |
|
| Rated operational voltage, AC |
202-480 V |
| Operating voltage range, AC |
180-528 V |
| Rated operation current Ie at AC-1 |
50 A |
| Rated load current Close mounting |
40 A |
| Permissible I²t value |
1800 A²s |
| Height |
100 mm |
| Width |
110 mm |
| Depth |
100 mm |
| Supply voltage DC |
12-24 V |
| Control current max. |
7 mA |
| Must operate voltage max. |
9.2 V |
| Must release voltage min. |
1 V |
| Maximum operating temperature |
80 °C |
| Minimum operating temperature |
-30 °C |
| Isolation |
Phototriac |
| Switching at zero-crossing |
