Omron CP2E-N20DT1-D (CP2E-N20DT1-D)

Marka : Omron

Fiyat : ₺0,00 + KDV

KDV Dahil : ₺0,00

FİYAT VE TESLİM SÜRESİ İÇİN LÜTFEN İLETİŞİME GEÇİNİZ!

CP2E series compact PLC - Network type; 12 DI, 8DO; PNP output; Power supply 24 VDC; 10 kStep Program memory

ADET

Supply voltage type	DC
Number of digital inputs	12
Input type	PNP/NPN
Number of digital outputs	8
Output type	PNP
Program capacity	20 K steps
Data memory capacity	16 K words
Logic execution time	0.23 µs
Communication port(s)	Ethernet TCP/IP
Number of Ethernet ports	1
Number of USB ports	0
Number of RS-232 ports	0
Number of RS-485 ports	0
Communication option(s)	Serial RS-232C, Serial RS-422, Serial RS-485
Number of encoder input channels	6
Max. encoder input frequency	100 kHz
Max. number of PTP axes	2
Max. pulse output frequency	100 kHz
Function Block programming
Battery-free memory backup
Real-time clock
Analog option boards
Max. number of analog I/O channels	4
Max. number of local I/O points	20
Max. number of expansion units	0
Built-in auxiliary 24 VDC output	0 mA
Operating temperature range	-20-60 °C
Height	90 mm
Width	86 mm
Depth	80 mm
Weight	0 g
